Automatic Oil Acidity Tester LB-100AT

Automatic Oil Acidity Tester LB-100AT is a micro-computer controlled system with neutralization titrator. It is characterized by automatic change over and testing between six sample cups for parallel comparison of acid value testing results.

Specifications

Testing range	0.0005 mg KOH/g ~ 0.5000 mg KOH/g
Accuracy	Acid value: 0.001 mg KOH/g; deviation: 0.005 mg KOH/g Acid value: 0.1 mg KOH/g; deviation: 5% of indications
Resolution ratio	0.0001 mg KOH/g
Repeatability	0.004 mg KOH/g
Relative humidity	≤ 85 %
Power supply	220 V ± 10 %; 50 Hz ± 5 %
Dimensions	440 × 300 × 220 mm
Weight	16 kgs

Features

Digital color LCD screen for visual monitoring
High quality cold rolled steel plates with electrostatic sprayed anti-corrosive exterior
Automatic liquid adding, titration, stirring
Automatic storage capacity and printing of around 260 groups testing data
Proceeds auto-check for breakdown
Pipeline auto cleans for smooth and blockage free flow
Automatic end point estimation

Applications

Used for acid testing acid values of transformer oil, steam-turbine oil, fire- resistant oil, diesel oil, gasoline, etc. in the fields of chemical industries, power industries, petroleum plants, etc.
