Chlorophyll Meter LB-10CM

Name: Chlorophyll Meter LB-10CM
Brand: Labotronics
SKU: LB-10CM
Rating: 4.6 (513 reviews)

Chlorophyll Meter LB-10CM features a small measurement area of 2 mm × 3 mm for analyzing even small leaves. It can measure leaves with a thickness of up to 1.2 mm and offers an adjustable stopper for accurate leaf positioning at depths from 0 to 6 mm. Our meter provides precise, non-destructive measurements of chlorophyll content in crop leaves. Its water-resistant design ensures reliable performance even in outdoor environments.

$ 3150

Download Catalog

Specifications

Measurement Range	- 9.9 to 199.9 SPAD units
Measurement Accuracy	± 1.0 SPAD units (0.0 to 50.0 SPAD)
Repeatability	± 0.3 SPAD units
Reproducibility	± 0.5 SPAD units (no change in sample position)
Measurement Subject	Crop leaves
Measurement Method	Optical density difference at 2 wavelengths
Measurement Area	2 mm × 3 mm
Maximum Subject Thickness	1.2 mm
Subject Insertion Depth	12 mm (adjustable stopper, 0 to 6 mm)
Operating Temperature Range	0 to 50°C
Light Source	2 LED elements
Receptor	Silicon photodiode (SPD)
Display	LCD panel, 4-digit value, trend graph
Memory Function	Stores up to 30 values, averages data
Measurement Interval	Approx. 2 seconds
Temperature Drift	± 0.04 SPAD units/°C
Storage Temperature Range	- 20 to 55°C
Relative Humidity	≤ 85%
Power	2 AA alkaline batteries
Dimensions (W × H × D)	78 × 164 × 49 mm
Weight	200 g

Features

Lightweight and portable unit
Non-destructive leaf measurements
Water-resistant unit
Supports data storage, averaging, and recall

Standard Accessories

Depth Stop

Strap

2 AA-size Alkaline Batteries

Soft Case

Reading Checker

Applications

Chlorophyll Meter LB-10CM is used for measuring chlorophyll content in crop leaves. It is ideal for agricultural research, farming, and plant health monitoring in outdoor environments.
