Jacketed Glass Reactor LB-94JGR
Jacketed Glass Reactor LB-94JGR has a capacity of 80 L, with a rotating speed from 0 rpm to 600 rpm. It is equipped with a maximum jacket pressure of 0.5 bar. It features PTFE wetted components in order to prevent corrosion and enhances chemical resistance. It has a large dual layer condenser for efficient condensation during distillation and reflux operations.
$ 6250
Download CatalogSpecifications
| Reaction volume | 80 L |
| Jacket volume | 20 L |
| Rotating speed | 0 rpm ~ 600 rpm |
| Working temp. range | -60 °C ~ 200 °C |
| Neck number on lid | 6 |
| Max jacket pressure | 0.5 bar |
| Overall dimension | 850 x 650 x 2700 mm |
| Motor power | 200 W |
Features
- Material: Stainless Steel 304 and epoxy-coating
- aluminumGlassware is made of borosilicate 3.3 glass for excellent chemical and physical performance
- Glass/PTFE wetted components for outstanding corrosion resistance
- Heating fluid inlet/outlet Ports: 20 mm glass hose barb
- Pressure rating: Full vacuum to atmosphere
- Cooling area: 0.2 m (double coil)
Applications
Used for biochemical and synthesis reaction-distillation, reflux, stirring, etc. at a constant temperature conditions
