Research biological microscope LB-11RBM is a unit with multiple splitting ratio options for professional analysis. Large sized rackless stage holds two slices simultaneously for comparative studies. Modular frame structure with cross arm and main body improves the system compatibility. Various optional accessories upgrades the unit and makes it more flexible for advanced application.
Buy Now Download Catalog Download ManualSpecifications
| Viewing head | Seidentopf Trinocular |
| Viewing head inclination | 30° inclined |
| Interpupillary distance | 50 mm ~ 76 mm |
| Frame | Biological frame (transmitted) |
| Splitting ratio Eyepiece | Trinocular = 100:0 or 20:80 or 0:100 |
| Eyepiece | PL 10X/25 mm Diopter adjustable |
| Objective (Plan semi-apochromatic fluorescent objective) | 4X/0.13 (infinity) ; WD = 18.5 mm 10X/0.30 (infinity) ; WD = 10.6 mm 20X/0.50 (infinity) ; WD = 2.33 mm 40X/0.75 (infinity) ; WD = 0.6 mm 100X/1.30 (infinity) ; WD = 0.21 mm |
| Nosepiece (with DIC slot) | Backward sextuple |
| Frame structure | Low position co-axial coarse and fine adjustment Coarse adjustment distance: 25 mm Fine precision: 0.001 mm |
| Stage (tension adjustable) | Double layers mechanical stage Size: 187 mm x 168 mm Moving range: 80 mm x 55 mm Precision: 0.1 mm Two-way linear drive |
| Condenser | Swing-out type achromatic condenser (N.A. 0.9) |
| Transmitted illumination | 12 V/100 W Halogen lamp house Center pre-set Intensity adjustable |
Features
Optional Accessories
| Accessory No | Accessory | Specifications |
| RBMA1 | Eyepiece | PL 10X/25 mm, diopter adjustable |
| RBMA2 | Eyepiece | PL 10X/26.5 mm , diopter adjustable |
| RBMA3 | Eyepiece | PL 10X/26.5 mm. with rectile, diopter adjustable |
| RBMA4 | Nosepiece | Backward Quintuple |
| RBMA5 | Nosepiece | Backward Septuple |
| RBMA6 | Camera adapter | 0.5X/0.65X/1X focusing C-mount |
| RBMA7 | Camera | Cooled CCD Camera |
| RBMA8 | Calibration slide 0.01 mm | |
| RBMA9 | Attachment | DIC attachment |
Applications
Used in biology, histology, pathology, bacteriology, pharmacy, medical laboratories and education institutes to observe cell, tissues and other specimens.
| Viewing head | Seidentopf Trinocular |
| Viewing head inclination | 30° inclined |
| Interpupillary distance | 50 mm ~ 76 mm |
| Frame | Fluorescence frame (transmitted) |
| Viewing head | Seidentopf Trinocular |
| Viewing head inclination | 30° inclined |
| Interpupillary distance | 50 mm ~ 76 mm |
| Frame | Biological frame (transmitted) |
