Intelligent hotplate stirrer LB-23HPS

Intelligent hotplate stirrer LB-23HPS

Intelligent hotplate stirrer LB-23 HPS is a black ceramic top hotplate stirrer with a stirring range of 0 rpm to 2000 rpm. Features a stirring capacity for flasks ranging from 50 ml to 15 L. It is equipped with PID controlled temperature of 400 °C for uniform heat distribution. It offers digital temperature control and an outer thermo that measures and controls the liquid temperature value together with the front panel. The inner thermo, controls and measures the hotplate stirrer temperature.

Buy Now Download Catalog

Specifications

Stirring capacity 50 ml ̴ 15 L
Top ceramic dimension 280 mm × 280 mm
Power 750 W
Temperature 400 °C
Stirring range 0 rpm ~ 2000 rpm
Stirring speed accuracy ± 1 rpm
Temperature accuracy ± 1 °C
Voltage 160 V ̴ 240 V, 110 V ̴ 120 V
Motor power 40 W, DC 20 V
Weight 9.3 kgs

Features

  • Stirring range from 0 rpm to 2000 rpm
  • Black ceramic top offers scratch resistance
  • Corrosion resistant in salt water and acid
  • Continuous working time
  • PID controlled temperature
  • Electronic speed control for constant speed even during change in load
  • Individual unit operation or all units controlled operational modes (Flexible)

Applications

Used in laboratories to apply heat to containers , samples , for distillations that require high temperatures , health care and other fields

Standard Accessories

Accessory No Accessory Number
A1 Removable holder 1 PC
A2 Clamp with screw 1 PC
A3 Inner Thermocouple 4-spin 1 PC
A4 Outer Thermocouple 1 PC
A6 Four-finger Extension Clamp, Length 300 mm 1 PC
A8 Magnetic stir bar  White PTFE-coated  Length: 30mm  Diameter :6 mm 1 PC
