Nitrogen Cabinet LB-15NC has a storage capacity of 540L and maintains humidity levels between 1% to 60% RH. It supports up to 80kg/shelf load capacity, allowing flexible storage configurations. Its high-precision temperature and humidity sensor ensures stable and consistent storage conditions. Our nitrogen cabinet provides ultra-low humidity for the secure storage of moisture and oxygen-sensitive components.
$ 2793.75
Download CatalogSpecifications
| Capacity | 540L |
| Humidity Range | 1 to 60% RH (Adjustable) |
| Number of Shelves | 3pcs (Height adjustable) |
| Maximum Load Capacity | 80 kg/shelf |
| Recovery Time | Maximum 15 min recovery after a 30-sec door opening (Ambient 25℃, 60%RH) |
| Material | 1.2 mm thick galvanized steel with ESD-safe coating |
| Power Consumption | 10W |
| Inner Dimension (W × D × H) | 596 × 682 × 1298 mm |
| Outer Dimension (W × D × H) | 598 × 710 × 1465 mm |
| Net Weight | 68 kg |
| Gross Weight | 95 kg |
Features
Adjustable humidity control
Height-adjustable shelves
Automated nitrogen control
ESD-safe coating
Fast recovery time
Calibration reminder
Applications
Nitrogen Cabinet LB-15NC is ideal for storing moisture-sensitive and oxygen-sensitive components in ultra-low humidity environments. It is widely used in electronics manufacturing, semiconductor production, aerospace industries, and research laboratories.
