Single Glass Jacketed Reactor LB-73SGR
Single Glass Jacketed Reactor LB-73SGR features a 3 L capacity, ensuring excellent chemical resistance and thermal stability. It operates within a temperature range of -80 °C to +250 °C, providing accurate and stable conditions. It maintains a vacuum degree of 0.098 MPa, ensuring efficient solvent recovery. It is made from durable construction, ensuring long-lasting performance and reliability in demanding environments.
$ 1900
Download CatalogSpecifications
| Capacity | 3 L |
| Temperature Range of Glass Vessel | -80℃ to 250℃ |
| Bath Temperature Control Range | RT to 180℃ |
| Temperature Measurement Accuracy | ±1℃ |
| Stirring Speed | 0 to 800 rpm |
| Vacuum Degree | 0.098 MPa |
| Glass Vessel Diameter | Φ195mm |
| Dropping Funnel | 500ml |
| Stirring Motor Power | 90W |
| Heating Power | 1.5kW |
| Power Supply | 220V/50Hz |
| Dimensions | (430 to 1030) × 330 × 1100 mm |
| Weight | 23kg |
Features
Borosilicate glass construction
Digital control interface
High-torque stirring motor
Brushless copper motor
Double sealing system
Applications
Single Glass Jacketed Reactor LB-73SGR is used for chemical synthesis, pharmaceutical formulation, and extraction processes. It is widely utilized in university research, chemical and biological laboratories, biopharmaceutical industries, aerospace, and healthcare.
