Clean oven LB-40CLO

Name: Clean oven LB-40CLO
Brand: Labotronics
SKU: LB-40CLO
Rating: 4.9 (548 reviews)

Clean oven LB-40CLO is facilitated with rapid heating and working temperature of 10 °C to 200 °C. Built-in fiberglass wool insulated layer prevents heat loss. Circulating fan motor hot air ensures uniform temperature distribution in a chamber. Humidifying system overheating protection prevents unit damage.

$ 11762.5

Download Catalog

Specifications

Capacity	600 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1500 x 1700 x 750 mm
Power supply	AC 3 phase 380 V
Interior dimensions ( W x H x D )	1000 x 1000 x 600 mm
Temperature fluctuation	± 0.3 °C
Temperature uniformity	1 °C
Load	20 kg per shelf
Door	Single door Explosion-proof lock Silicone gaskets
Inner chamber material	SUS#304
External chamber material	Cold-rolled plate with powder coated finishing
Insulation	Fiberglass wool
Controller	Temperature controller, digital set mode, digital display, PID auto calculation, SSR control, single segmentation control
Heater	Oval electrical heating ceramic tile Low radiation electrical heater
Air filter	HEPA filter
Wind cycling system	Motor with centrifugal fan for uniform wind
Air ventilation system	Adjustable air throttle, directly connected with air exhaust duct
Surrounding temperature range	0 ℃ ~ 30 ℃
Surrounding relative humidity	≤ 85 % RH
Atmospheric pressure	0.086 MPa ~ 0.106 MPa
Ambient air requirements	No high concentrations of dust, flammable and explosive gas, strong electromagnetic radiation source nearby
Prohibited items for the unit	Flammable explosive volatile material sample test or storage Corrosive substance sample test or store Biological sample test or store Strong electromagnetic emission source test or store

Features

Temperature controller
Digital set mode and display
PID controlled auto calculation
Single segmentation control
Solid state relay control ( SSR control )
Low radiated oval electrical heating tile
Adjustable air throttle ( directly connected to air exhaust duct )
Overheating circuit-breaker, compressor and control system overload protection, humidifying system overheating protection, breakdown light indicator
Optional appearance (Dual doors, dual layers, stainless steel shell, without viewing window)

Standard Accessories

Accessory No	Accessory	Quantity
1.	Electrical heater	1 piece
2.	Non fuse switch	2 piece
3.	3 meter power cord	1 piece
4.	Tray stand	2 piece
5.	Timer	1 piece

Get Quote

Clean oven LB-301CLO

Capacity	480 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1300 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 9712.5

Clean oven LB-600CLO

Capacity	1000 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1700 x 1700 x 900 mm
Power supply	AC 3 phase 380 V

$ 20762.5

Clean oven LB-30CLO

Capacity	480 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1300 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 10675

Clean oven LB-51CLO

Capacity	720 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1700 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 9475

Clean oven LB-501CLO

Capacity	720 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1700 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 11712.5

Clean oven LB-201CLO

Capacity	270 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1100 x 1600 x 650 mm
Power supply	AC 3 phase 380 V

$ 8250

Clean oven LB-21CLO

Capacity	270 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1100 x 1600 x 650 mm
Power supply	AC 3 phase 220 V

$ 6237.5

Clean oven LB-50CLO

Capacity	720 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1700 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 13537.5

Clean oven LB-500CLO

Capacity	720 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1700 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 17212.5

Clean oven LB-601CLO

Capacity	1000 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1700 x 1700 x 900 mm
Power supply	AC 3 phase 380 V

$ 13637.5

Clean oven LB-100CLO

Capacity	72 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	900 x 1050 x 550 mm
Power supply	AC 1 phase 220 V

$ 6037.5

Clean oven LB-200CLO

Capacity	270 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1100 x 1600 x 650 mm
Power supply	AC 3 phase 380 V

$ 12987.5

Clean oven LB-41CLO

Capacity	600 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1500 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 8200

Clean oven LB-61CLO

Capacity	1000 L
Temperature range	RT 10 ℃ ~ 200 ℃
Dust class	Class 10000
Exterior dimensions ( W x H x D )	1700 x 1700 x 900 mm
Power supply	AC 3 phase 380 V

$ 11175

Clean oven LB-300CLO

Capacity	480 L
Temperature range	RT 10 ℃ ~ 300 ℃
Dust class	Class 100 / Class 1000
Exterior dimensions ( W x H x D )	1300 x 1700 x 750 mm
Power supply	AC 3 phase 380 V

$ 14762.5
