Horizontal Autoclave LB-12HCA offers a capacity of 280 L with a temperature range of 40 to 134 °C, ensuring versatile and efficient sterilization. It operates at a working pressure of 0.22 MPa, ensuring efficient and consistent sterilization throughout the chamber. It features automatic over-temperature and over-pressure protection for safety. Our autoclave is equipped with a safety interlock, preventing accidental steam release for safe operation.
$ 5906.25
Download CatalogSpecifications
| Capacity | 280 L |
| Temperature Range | 40 to 134 °C |
| Maximum Working Temperature | 134 °C |
| Temperature Uniformity | ≤ ± 2 °C |
| Working Pressure | 0.22 MPa |
| Maximum Working Pressure | 0.23 MPa |
| Timer Range | 0 to 60 min |
| Drying Time Range | 0 to 60 min |
| Power Consumption | 12 kW |
| Power Supply | AC 380 V; 50 Hz |
| Interior Dimension | Φ 600 × 1000 mm |
| Exterior Dimension | 1400 × 770 × 1780 mm |
| Packaging Dimension | 1680 × 920 × 2100 mm |
| Net Weight | 365 kg |
| Gross Weight | 465 kg |
Features
Pressure alarm
Safety valve
Low water protection
Overcurrent protection
Stainless steel chamber
Energy-efficient operation
User-friendly interface
Applications
Horizontal Autoclave LB-12HCA is designed for sterilizing surgical tools, lab utensils, and test fabrics. It is used in hospitals, operating rooms, pharmaceutical units, and scientific research labs.
Frequently asked questions For Horizontal Autoclave
1. How does the Labotronics Horizontal Autoclave LB-12HCA ensure consistent sterilization results?
Labotronics Horizontal Autoclave LB-12HCA maintains uniform temperature distribution within ±2 °C, ensuring reliable sterilization of all items inside the chamber.
2. What safety mechanisms are integrated into the Labotronics Horizontal Autoclave LB-12HCA?
Labotronics LB-12HCA includes a safety valve, pressure alarm, interlock system, and automatic shutdown under abnormal conditions to maximize operational safety.
3. How does the Labotronics Horizontal Autoclave LB-12HCA protect delicate instruments?
Labotronics Horizontal Autoclave LB-12HCA uses precise temperature and pressure control, preventing overheating or pressure surges that could damage sensitive instruments.
4. What role does the digital control panel play in Labotronics Horizontal Autoclaves?
Labotronics Horizontal Autoclaves integrate digital displays that provide real-time monitoring of temperature, pressure, and cycle status, ensuring smooth and user-friendly operation.
5. How do Labotronics Horizontal Autoclaves maintain temperature consistency across large chambers?
Labotronics Horizontal Autoclaves are designed with advanced heating and circulation systems that ensure uniform temperature distribution, preventing hot or cold spots inside the chamber.
6. Do Labotronics Horizontal Autoclaves provide flexibility in sterilization cycles?
Yes, Labotronics Horizontal Autoclaves offer adjustable temperature ranges and cycle settings, allowing users to sterilize different types of materials efficiently in one system.
7. How do Labotronics Horizontal Autoclaves handle cold air removal during sterilization?
Labotronics Horizontal Autoclaves are designed with efficient air displacement and exhaust systems, ensuring complete removal of cold air to achieve reliable sterilization conditions.
8. How do Labotronics Horizontal Autoclaves handle water shortages during operation?
Labotronics Horizontal Autoclaves are equipped with automatic low-water level protection systems, preventing cycle interruptions and protecting the heating elements.
