Microwave Digestion System LB-10MDS

Name: Microwave Digestion System LB-10MDS
Brand: Labotronics
SKU: LB-10MDS
Rating: 4.6 (510 reviews)

Microwave Digestion System LB-10MDS offers a 100 mL reaction tank capacity, ensuring efficient and accurate sample digestion. It features rapid sample preparation, reducing digestion time by up to 90% to improve laboratory efficiency. It offers expandable capacity to suit both small-scale and high-volume sample processing. Our microwave digestion system includes a 7-inch large touch LCD screen for easy operation and real-time monitoring.

$ 12250

Download Catalog

Specifications

Reaction Tank Capacity	100 mL
Batch Volume	6
Maximum Temperature	≥ 300°C
Working Temperature Range	0 to 40°C
Humidity Range	15 to 80% RH
Microwave Cavity	65L, 316L stainless steel, multi-layer corrosion-resistant PFA Teflon coated
Microwave Source	2450 MHz, dual magnetron
Pressure Control	G-pressure monitors, overpressure adjustment, and automatic alarm
Pressure Measurement	Piezoelectric pressure sensor External digestion tank pressure: ≥ 20MPa Inner digestion tank pressure: ≥ 4MPa Volume: ≥ 100 mL
Pressure Display Accuracy	± 0.1 MPa
Temperature Measurement	Optical fiber sensor (-50 to 350°C)
Temperature Control Accuracy	± 0.1°C
Full-Tank Temperature Range	0 to 350°C
Control Accuracy	± 0.1°C
Communication Interface	USB, RS-232
Furnace Exhaust System	High-power corrosion-resistant axial fan; cools from 200°C to 60°C in 15 minutes
Inner Tank Material	TFM
External Tank Material	PEEK (explosion-proof)
Digesting Rotor Frame	High-strength integrated turntable frame
Display Screen	7-inch large touch LCD
Software System	ARM chip with ZG operating system
Power Consumption	3200W Microwave: 2200W
Power Supply	220 to 240 VAC, 50/60Hz, 15A
Dimension (W × D × H)	580 × 680 × 720 mm
Net Weight	65 kg

Features

Chemically resistant vessels
Remote monitoring capability
Even heat distribution
Durable tank construction
Contamination-free digestion
Automatic sensor calibration

Applications

Microwave Digestion System LB-10MDS is used for fast, contamination-free sample digestion before elemental analysis. It is ideal for preparing samples in environmental, food, pharmaceutical, and mining laboratories.

Get Quote

Microwave Digestion System LB-21MDS

Volume of Resonant Cavity	48L
Pressure Management Range	70Mpa
Pressure Accuracy	± 0.01Mpa
Temperature Management Range	0°C to 305 °C
Temperature Accuracy	± 1℃

$ 37500

Microwave Digestion System LB-14MDS

Reaction Tank Capacity	55, 100, 110 mL
Batch Volume	Maximum 40 Positions
Maximum Temperature	≥ 300°C
Working Temperature range	0 to 40°C
Humidity Range	15 to 80% RH

$ 32550

Microwave Digestion System LB-11MDS

Reaction Tank Capacity	100 mL
Batch Volume	10
Maximum Temperature	≥ 300°C
Working Temperature Range	0 to 40°C
Humidity Range	15 to 80% RH

$ 15050

Microwave digestion system LB-20MDS

Volume of resonant cavity	32 L
Temperature measurement range	0 °C to 300 °C
Temperature measure precision	± 1 °C
Pressure measurement range	0 to 50 bar
Pressure measure precision	± 0.1 bar
