High Speed Refrigerated Centrifuge LB-21HRC reaches a maximum speed of 23000 rpm and achieves a maximum RCF of 37023 × g. It supports up to 1000 user-defined programs, allowing for customization across a wide range of protocols. The digital touch screen interface provides real-time monitoring of operational parameters. It features up to 7 stages of multi-stage centrifugation, ensuring rapid and efficient sample separation.
Buy Now Download CatalogSpecifications
| Maximum Speed | 23000 rpm |
| Maximum RCF | 37023 × g |
| Maximum Capacity | 4 × 750 mL |
| Speed Accuracy | ± 10 rpm |
| Temperature Range | -20℃ to +40℃ |
| Temperature Accuracy | ±1℃ |
| Timer Range | 1s to 99h 59m 59s |
| Noise Level | ≤ 56dB(A) |
| Power Consumption | 1500W |
| Dimension | 600 × 680 × 420 mm |
| Weight | 108 kg |
Features
RFID rotor detection
CFC-free refrigerant
Over-temperature protection
Low vibration operation
Autoclavable rotors
Auto-start refrigeration
Imbalance detection
Applications
High Speed Refrigerated Centrifuge LB-21HRC is used for rapid and efficient sample separation. It is ideal for use in clinical labs, research centers, pharmaceutical industries, and biotechnology labs.
Rotor Selections
Rotor Type | Capacity | Maximum Speed | Maximum RCF |
Fixed Angle Rotor 1 | 12 × 1.5/2.2ml | 23000rpm | 37023 × g |
Fixed Angle Rotor 2 | 16 × 5ml | 18000rpm | 26334 × g |
Fixed Angle Rotor 3 | 24 × 1.5/2.2ml | 16500rpm | 26389 × g |
Fixed Angle Rotor 4 | 24 × 1.5/2.2ml (aerosol tight) | 18000rpm | 31405 × g |
Fixed Angle Rotor 5 | 12 × 10ml | 15500rpm | 22213 × g |
Fixed Angle Rotor 6 | 36 × 1.5/2.2ml | 15000rpm | 21784 × g |
Fixed Angle Rotor 7 | 6 × 50ml conical bottom | 13000rpm | 18440 × g |
Fixed Angle Rotor 8 | 6 × 50ml round bottom | 13500rpm | 19886 × g |
Fixed Angle Rotor 9 | 48 × 1.5/2.2ml | 13000rpm | 18535 × g |
Fixed Angle Rotor 10 | 4 × 100ml | 12000rpm | 15906 × g |
Fixed Angle Rotor 11 | 8 × 50ml conical bottom | 12000rpm | 16710 × g |
Fixed Angle Rotor 12 | 8 × 50ml round bottom | 12000rpm | 15906 × g |
Fixed Angle Rotor 13 | 12 × 15ml | 13000rpm | 18667 × g |
Fixed Angle Rotor 14 | 6 × 100ml | 10000rpm | 12063 × g |
Fixed Angle Rotor 15 | 8 × 15ml | 14500rpm | 18593 × g |
Fixed Angle Rotor 16 | 12 × 50ml (conical bottom) | 10000rpm | 14310 × g |
Microplate Rotor 1 | 2 × 3 × 96 well plate | 4000rpm | 2003 × g |
Microplate Rotor 2 | 4 × 2 × 96 well plate | 4200rpm | 3551 × g |
Swing-out Rotor 1 | 4 × 250ml | 4500rpm | 3735 × g |
Swing-out Rotor 2 | 48 × 2 - 7ml (blood tube) | 4000rpm | 2951 × g |
Swing-out Rotor 3 | 64 × 2 - 7ml (blood tube) | 4000rpm | 2951 × g |
Swing-out Rotor 4 | 4 × 500ml | 4200rpm | 3551 × g |
Swing-out Rotor 5 | 148 × 5ml (RIA tube) | 4200rpm | 3551 × g |
Swing-out Rotor 6 | 96 × 2 - 7ml (blood tube) | 4200rpm | 3551 × g |
Swing-out Rotor 7 | 4 × 750ml | 4000rpm | 3500 × g |
Swing Bucket Rotor 1 | 20 × 50ml | 4200rpm | 3551 × g |
Swing Bucket Rotor 2 | 40 × 15ml | 4200rpm | 3551 × g |
Swing Bucket Rotor 3 | 80 × 10ml (blood tube) | 4200rpm | 3551 × g |
Swing Bucket Rotor 4 | 112 × 2 - 7ml (blood tube) | 4200rpm | 3551 × g |
Swing Bucket Rotor 5 | 100 × 1.5ml | 4200rpm | 3551 × g |
Adapter Selection
Adapter Type | Capacity | Maximum Speed | Maximum RCF |
Adapter1 | 8 × 50ml | 4500 rpm | 3735 × g |
Adapter 2 | 20 × 15ml | 4500 rpm | 3735 × g |
Adapter 3 | 36 × 10ml | 4500 rpm | 3735 × g |
Adapter 4 | 40 × 7ml blood tube | 4500 rpm | 3735 × g |
Adapter 5 | 16 × 50ml normal | 4200rpm | 3551 × g |
Adapter 6 | 16 × 50ml aerosol tight | 4200rpm | 3551 × g |
Adapter 7 | 36 × 15ml normal | 4200rpm | 3551 × g |
Adapter 8 | 36 × 15ml aerosol tight | 4200rpm | 3551 × g |
Adapter 9 | 76 × 2 -7ml blood tube | 4200rpm | 3551 × g |
Adapter 10 | 76 × 2 -7ml blood tube aerosol tight | 4200rpm | 3551 × g |
Adapter 11 | 12 × 100ml | 4000rpm | 3500 × g |
Adapter 12 | 20 × 50ml | 4000rpm | 3500 × g |
Adapter 13 | 28 × 50ml | 4000rpm | 3500 × g |
Adapter 14 | 56 × 15ml | 4000rpm | 3500 × g |
Adapter 15 | 96 × 2-7ml blood tube | 4000rpm | 3500 × g |
Frequently asked questions For
1. What are high-speed refrigerated centrifuges?
High-speed refrigerated centrifuges are laboratory instruments used for the rapid separation of samples at high rotational speeds while maintaining low temperatures to preserve sample integrity.
2. Do you offer different models of high-speed refrigerated centrifuges?
Yes, Labotronics offers a variety of high-speed refrigerated centrifuges with different capacities, speed settings, and rotor configurations to meet diverse laboratory needs.
3. What types of samples can be processed with high-speed refrigerated centrifuges?
Our centrifuges can process a wide range of biological and chemical samples, including blood, plasma, serum, DNA/RNA, proteins, and various chemical compounds.
4. Where are high-speed refrigerated centrifuges typically used?
Labotronics' high-speed refrigerated centrifuges are suitable for use in medical laboratories, biotechnology research centers, pharmaceutical industries, food testing labs, and environmental analysis facilities, particularly for handling sensitive biological and chemical samples.
