High speed refrigerated centrifuge LB-22HRC

High speed refrigerated centrifuge LB-22HRC

High speed refrigerated centrifuge LB-22HRC is a microcomputer controlled centrifuge with high refrigeration efficiency. Features an electric door that provides better safety. Digitalized LCD panel for viewing ongoing parameters with simultaneous regulation of speed and time. The parameters can be changed anytime during the process without any downtime.

Buy Now Download Catalog

Specifications

Max speed 23000 rpm
Max RCF 33097 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Temperature accuracy ± 2 °C
Noise ≤ 55 dB
Time range (hh:mm:ss) 1 min ̴ 99:99:59
Power supply AC 220 V 50 Hz
Power 1500 W
Dimensions 585 x 580 x 500 mm
Weight 95 kgs

Features

  • Nine ascending and descending rate selection mode
  • Ten work mode options that can free programming call
  • Double synchronous display screen
  • Full steel structure with stainless steel centrifugal cavity
  • Two optional timing mode with easy switching options
  • Magnetic locks and double lock rod design doors
  • AC frequency conversion motor drive

Applications

Used for handling larger sample sizes at high angular velocities. They are ideal for a wide range of separation tasks used in the cell culture and clinical sectors involving DNA, RNA, viruses, proteins and more.

Rotor Selections

Model Max speed Max RCF Rotor capacity
Angle rotor 01 21000 rpm 25622 x g 24 × 0.2 ml
Angle rotor 02 23000 rpm 26614 x g 12 × 0.5 ml
Angle rotor 03 18000 rpm 23846 x g 24 × 0.5 ml
Angle rotor 04 21500 rpm 33097 x g 12 × 1.5 ml /2.2 ml
Angle rotor 05 16000 rpm 22810 x g 24 × 1.5 ml /2.2 ml
Angle rotor 06 16000 rpm 17459 x g 12 × 5ml
Angle rotor 07 14000 rpm 18188 x g 12 × 10 ml
Angle rotor 08 12000 rpm 14170 x g 8 × 15 ml
Angle rotor 09 12000 rpm 16099 x g 6 × 50 ml
Angle rotor 10 12000 rpm 14645 x g 6 × 100 ml
Angle rotor 11 14000 rpm 13367 x g 8 × 4 × 0.2 ml (PCR special rotor)
Angle rotor 12 16000 rpm 31482 x g 48 × 0.5 ml
Angle rotor 13 16000 rpm 26331 x g 36 × 1.5 ml /2.2 ml
Swing out 01 5000 rpm 3775 x g 4 × 50 ml

Request Quotation

High speed refrigerated centrifuge

Max speed 18000 rpm
Max RCF 23846 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Speed range 18500 rpm
Maximum RCF 23900 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 99 mins
Max speed 18000 rpm
Max RCF 23486 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Max speed 18000 rpm
Max RCF 23486 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Max speed 23000 rpm
Max RCF 33097 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Maximum speed 16000 rpm, ±10 revolution/min
Maximum RCF 27762×g
Maximum capacity 4×1000 ml
Temperature range -20 to 40°C
Speed range 10000 rpm
Maximum RCF 18300 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 23 hrs. 59 mins
Speed range 16000 rpm
Maximum RCF 18800 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 99 mins
Speed range 22000 rpm
Maximum RCF 32465 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 99 mins
Max speed 23000 rpm
Max RCF 33097 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C
Max speed 16500 rpm
Max RCF 26145×g
Max capacity 6×50 ml
Revolutions/min ±10 rpm
Maximum Speed 20000 rpm
Maximum RCF 31115 × g
Maximum Capacity 4 × 250 ml
Speed Accuracy ± 10 rpm
Speed range 21000 rpm
Maximum RCF 47580 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 23 hrs. 59 mins
Speed range 23000 rpm
Maximum RCF 35500 × g
Speed accuracy ± 20 rpm
Time range 1min ~ 9 hours 99 mins
Max speed 16500 rpm
Max RCF 20038 x g
Speed accuracy ± 100 rpm
Temperature range -20 °C to -40 °C

A mini centrifuge is a compact and versatile laboratory device designed for the quick and efficient separation of small volumes of biological and chemical samples. Operating at speeds of up to 6,000 revolutions per minute (RPM), it utilizes specially designed rotors to generate centrifugal forces, allowing for the separation of substances based on their density. Our laboratory centrifuge is ideal for applications such as microfiltration, PCR preparation, and DNA purification, making it an essential tool for small-scale experiments and procedures. Its small, portable design, often powered by batteries or a USB connection, makes it suitable for fieldwork and limited bench space while offering user-friendly controls for ease of operation, making it a valuable asset in various laboratory settings.

Speed range 5400 rpm
Maximum RCF 2000 ×g
Speed accuracy 5400 rpm (fixed)
Time range Continuous operation
Speed range 1000 rpm ~ 14,500 rpm
Maximum RCF 14,100 × g
Speed accuracy 100 rpm
Time range 15 s to 99 mins / continuous operation
Speed range 4500 rpm
Max. RCF (Round rotor) 2500 x g
Max. RCF (Strip rotor) 2800 x g
Speed accuracy ± 200 rpm
Speed range 7200 rpm
Max. RCF (Round rotor) 2500 x g
Max. RCF (Strip rotor) 2800 x g
Speed accuracy ± 200 rpm

Labotronics micro centrifuge is a compact and high-speed laboratory instrument designed for the quick and efficient separation of small volumes of biological and chemical samples. Operating at speeds often exceeding 10,000 revolutions per minute (RPM), it utilizes specially designed rotor assemblies to generate powerful centrifugal forces, facilitating the separation of substances based on their density. With its small footprint, it's perfect for applications like DNA and RNA purification, protein analysis, and microcentrifugation. Our versatile tool is essential for labs that require rapid sample processing, delivering reliable results in a matter of minutes, and it often features user-friendly controls and safety mechanisms for ease of use.

Speed range 500 rpm ~ 15000 rpm
Maximum RCF 15100 ×g
Speed accuracy ± 20 rpm
Time range 30 s to 99 mins
Microfuge LB-22HM
Speed range 14800 rpm
Maximum RCF 16300 × g
Speed accuracy 100 rpm
Time range 1 min to 99 mins

Microfuge LB-23HM

Speed range 16000 rpm
Maximum RCF 21000 × g
Speed accuracy 100 rpm
Time range 1 min to 99 mins

Our clinical centrifuge is a laboratory device commonly used in healthcare and medical settings for the separation of biological samples, particularly blood, urine, and other bodily fluids. It operates on the principle of centrifugal force, causing denser particles to settle at the bottom while lighter components rise to the top. Clinical centrifuges are vital tools for diagnostic and research purposes, enabling the separation of blood into its constituent components: plasma, red blood cells, and platelets. This separation is crucial for various medical tests, including hematocrit measurement, serum preparation for chemical analysis, and the isolation of specific biomolecules like DNA, RNA, and proteins. Our clinical centrifuges come in various sizes and capacities, making them versatile for a range of applications in hospitals, clinical laboratories, and research institutions. They are designed with safety features and easy-to-use controls, ensuring accurate and efficient sample processing while maintaining the integrity of the separated components for accurate diagnostic results

Speed range 200 rpm ~ 4500 rpm
Maximum RCF 2490 ×g
Speed accuracy ± 20 rpm
Time range 30 s ~ 99 mins / Continuous operation
Speed range 300 rpm ~ 4500 rpm
Maximum RCF 2490 ×g
Speed accuracy ± 20 rpm
Time range 30 s ~ 99 mins / Continuous operation

Our hematocrit centrifuge is a specialized laboratory centrifuge designed to measure the hematocrit level in blood samples. Hematocrit is the proportion of red blood cells (RBCs) in the total volume of blood, expressed as a percentage. This instrument operates by spinning capillary tubes filled with a small amount of whole blood at high speeds. The centrifugal force causes the denser red blood cells to settle at the bottom of the tube, while the less dense plasma rises to the top. By measuring the height of the RBC layer relative to the total column of blood, the hematocrit value is determined. Hematocrit levels are essential for diagnosing and monitoring various medical conditions, including anemia, polycythemia, and dehydration, and are routinely assessed in clinical laboratories, hospitals, and medical practices to provide critical information for patient care and treatment decisions.

Speed range 200 rpm ~ 14000 rpm
Maximum RCF 18620 × g
Speed accuracy ± 30 rpm
Time range 30 s ~ 99 mins

Labotronics blood ID centrifuge is a specialized laboratory centrifuge designed for rapid and efficient blood sample separation. It plays a crucial role in diagnostic and clinical settings, particularly in blood banks, hospitals, and research laboratories. This laboratory centrifuge accommodates blood collection tubes and uses centrifugal force to separate whole blood into its individual components, including red blood cells, plasma, and platelets. The separated components can then be further analyzed, processed, or stored for various medical procedures such as blood transfusions, diagnostic testing, and research applications. Our blood ID centrifuges are essential tools for ensuring the availability of safe and properly categorized blood products, aiding in disease diagnosis, and advancing medical research in fields like hematology and immunology. Their design often incorporates safety features to prevent sample cross-contamination and maintain the integrity of blood components.

Speed range 4000 rpm
Maximum RCF 1790 × g
Speed accuracy ± 20 rpm
Time range 1 min ~ 99 mins

Labotronics High Speed Centrifuges offer efficient and accurate sample separation for various laboratory applications. They provide adjustable speed control, allowing customization for different sample types. Their safety systems include automatic imbalance detection and secure lid locking, prioritizing user protection. They support interchangeable rotors, accommodating various tube sizes to meet specific separation needs. Their advanced cooling systems prevent overheating, protecting sensitive samples. Our High Speed Centrifuge features an intuitive digital display, for easy monitoring of multiple data settings.

Max speed 30,000 rpm
Max RCF 106,657 x g
Max capacity 4 x 1000 mL
Noise ≤ 65 dB
Max speed 6000 rpm
Max RCF 1248 x g
Capacity 2 x 8 x 0.2 ml
Noise ≤ 48 dB
Max speed 10000 rpm
Max RCF 6596 x g
Capacity 12 x 1.5/0.5/0.2 ml
Noise ≤ 48 dB
Max speed 12000 rpm
Max RCF 7567 x g
Capacity 6 x 1.5/0.5/0.2ml
Noise ≤ 48 dB

Our low-speed refrigerated centrifuge is a specialized laboratory device designed for separating substances of varying densities in biological and chemical samples. This laboratory centrifuge operates at relatively low speeds, typically ranging from 500 to 6,000 revolutions per minute (RPM), while maintaining a controlled, low-temperature environment to prevent sample degradation. It is ideal for applications such as DNA extraction, protein purification, and cell separation, offering efficient and precise separation capabilities for temperature-sensitive samples. The combination of low-speed operation and refrigeration ensures sample integrity and optimal results in a compact and user-friendly design.

Type Vertical
Max speed 4000 rpm
Max RCF 3309 x g
Swing rotor capacity 4 x 750 ml
Type Vertical
Max speed 4200 rpm
Max RCF 3387 x g
Swing rotor capacity 4 x 600 ml
Type Vertical
Max speed 4200 rpm
Max RCF 5116 x g
Swing rotor capacity 6 x 1000 ml
Type Benchtop
Max speed 4500 rpm
Max RCF 3524 x g
Swing rotor capacity 4 x 300 ml

Labotronics decanting low-speed centrifuge is a specialized laboratory centrifuge designed for the separation of substances in liquid suspensions or solutions at relatively low speeds. It operates on the principle of centrifugal force, gently accelerating samples to separate heavier particles or sediment from the liquid phase. Unlike high-speed centrifuges that are used for tasks like DNA isolation or protein purification, low-speed decanting centrifuges are ideal for applications where a more gentle separation process is required, such as separating cellular components from culture media, precipitates from solutions, or blood cells from plasma. They are commonly used in research, clinical, and industrial laboratories for their ability to clarify and process samples without causing damage or alteration to delicate particles.

Type Chest
Max speed 4000 rpm
Max RCF 3184 x g
Rotor capacity 124 x Vacuum blood tubes
Type Upright
Max speed 4000 rpm
Max RCF 3184 x g
Rotor capacity 124 x Vacuum blood tubes
Type Chest
Max speed 4000 rpm
Max RCF 3184 x g
Rotor capacity 148 x Vacuum blood tubes
Type Upright
Max speed 4000 rpm
Max RCF 3184 x g
Rotor capacity 148 x Vacuum blood tubes

Labotronics Low Speed Centrifuges deliver gentle and efficient separation of biological samples in medical and scientific environments. These centrifuges operate at controlled speeds, ideal for preserving the integrity of delicate cells and fluids. They feature fixed-angle rotors that accommodate multiple tube sizes, providing flexibility for various sample volumes. An intuitive LED display allows real-time monitoring of speed, force, and runtime. Labotronics centrifuges are ideal for clinical labs, research centers, medical facilities, educational institutions, blood banks, and biotech labs.

Max speed 5000 rpm
Max RCF 3175 x g
Rotor capacity 2 x 10 ml(carbon fiber rotor)
Speed accuracy ± 10 °C
Max speed 6000 rpm
Max RCF 5000 x g
Rotor capacity 4 x 100 ml
Temperature raise ≤ 10 °C
Max speed 6000 rpm
Max RCF 5000 x g
Rotor capacity 4 x 100 ml
Temperature raise ≤ 10 °C
Max speed 6000 rpm
Max RCF 5000 x g
Rotor capacity 15 ml / 20 ml x 6
Temperature raise ≤ 10 °C

Labotronics gerber centrifuge is a specialized laboratory instrument used in the dairy industry for the quantitative analysis of milk composition, particularly the measurement of milk fat content. It operates on the principle of centrifugal force, which separates the milk into its various components, including fat, skim milk, and water. The fat content is a critical parameter in dairy quality control, affecting factors like flavor, texture, and shelf life of dairy products. The Gerber method involves mixing a specific volume of milk with sulfuric acid and amyl alcohol, causing the fat to separate and form a distinct layer. Our gerber centrifuge then spins the sample to enhance the separation, and the fat content is determined by measuring the volume of the fat layer relative to the total volume of the sample

Maximum speed 1500 rpm
Maximum capacity 8 tubes (angle rotor)
Temperature range RT to 70°C
Timer 1 to 99 min 59 sec
Maximum speed 2400 rpm
Maximum capacity 12 tubes (swing rotor)
Temperature range RT to 70°C
Timer 1 to 99 min 59 sec

Labotronics Gel Card Centrifuge is a compact, high-speed instrument designed for efficient separation and analysis of gel cards used in blood typing and antibody detection. Employing centrifugal force, it rapidly spins gel cards, allowing precise identification of blood groups and antibodies. This automated process enhances diagnostic accuracy in transfusion medicine, streamlining blood compatibility testing. The Gel Card Centrifuge's user-friendly interface and reliable performance make it an indispensable tool in clinical laboratories, ensuring swift and accurate results for blood-related diagnostics.

Maximum Capacity 24 cards
Maximum Speed 4000 rpm
Maximum RCF 1825 ×g
Timing Range 1 s to 99 min

Labotronics Tubular Centrifuge has an enormous capacity. It offers quick and effective separation by a robust motor with high-speed rotation. Our centrifuge is adaptable and compact. It offers easy operation with intuitive controls. Its user-friendly design minimizes errors and reduces downtime. Enhanced efficiency and reliability improves separation processes to meet industrial or laboratory requirements.

Capacity 10 to 200 L/hr (Depend on solid content)
Inner diameter of drum 75 mm
Height 450 mm
Sedimentation volume 2.2 L

Labotronics Vacuum Concentrator Centrifuges offers efficient solvent removal and drying of various samples. Their advanced vacuum technology facilitates rapid solvent evaporation while preserving the integrity of sensitive samples. These centrifuges accommodate multiple tubes simultaneously, making them perfect for high-throughput environments. Their impressive drying speeds facilitate quick solvent extraction, yielding faster results. Ideal for isolating biological samples, chemicals, and other materials while preserving their integrity.

Max Speed 2000r/min
Max RCF 500 × g
Rotor Capacity 6 × 250mL
Adaptor Capacity 6 × 2 × 50 ml or 6 × 5 × 20mL

Labotronics Microplate centrifuges are designed for quick and efficient centrifugation of PCR plates, ELISA plates, and microtubes. They support various plate and tube formats, ensuring high-speed performance with precise control. They include a maintenance-free DC motor for reliable performance with minimal maintenance. These centrifuges operate with low noise and minimal vibration, ensuring stability during use. Our Microplate Centrifuge offers efficient separation of samples in research, clinical, and industrial applications.

Maximum Speed 3000 rpm
Increment Adjustable from 500 to 3000 rpm in 100 rpm Increment
Maximum RCF 600 × g
Sample Capacity 2 × 96-well PCR microplate / ELISA plate 24 × 0.2ml PCR tubes 192 × 0.2ml PCR tubes
