Temperature and Humidity Test Chamber LB-26THC provides 1000L testing capacity and operates efficiently at temperatures of up to 150°C. It comes with customizable temperature settings, ensuring reliable product testing. It includes a shallow slot steam humidification system for precise humidity control. Our test chamber features a digital display, enabling real-time monitoring of temperature and humidity levels.
$ 11837.5
Download CatalogSpecifications
| Capacity | 1000L |
| Temperature Range | 0 to 150°C -20°C to 150°C (Customizable) - 40°C to 150°C (Customizable) - 70°C to 150°C (Customizable) |
| Temperature Fluctuation | ≤ ±0.5°C |
| Temperature Uniformity | ≤ 2.0°C |
| Humidity Range | 20% to 98% R.H |
| Humidity Deviation | +2/-3% R.H |
| Heating Rate | 2.0 to 3.0°C/min |
| Cooling Rate | 0.7 to 1.0°C/min |
| Refrigerant | R404A/R23 |
| Humidification System | Shallow slot steam |
| Dehumidification System | Refrigeration dehumidification mode |
| Heating System | NiCr heater |
| Circulation System | Single-cycle, stainless-steel fan |
| Display | 7-inch Touch Screen Controller |
| Interior | Anti-corrosion SUS 304 mirror stainless steel |
| Exterior | Reinforced steel plate with electrostatic spraying |
| Insulation | Fiberglass wool/polyurethane foam |
| Power | 220V 50/60Hz, 380V 50/60Hz |
| Internal Dimension (W × D × H) | 1000 × 1000 × 1000 mm |
| External Dimension (W × D × H) | 1000 × 1000 × 1000 mm |
| Weight | 790 kg |
Features
Optional Accessories
Electronic Humidity Sensor (Humidity Transmitter)
Applications
Temperature and Humidity Test Chamber LB-26THC is perfect for evaluating product performance under controlled temperature and humidity conditions. It is ideal for industries such as electronics, automotive, aerospace, and pharmaceuticals.
Frequently asked questions For Temperature And Humidity Test Chamber
1. What is a Temperature and Humidity Test Chamber?
Temperature and Humidity Test Chamber is a laboratory or industrial device used to simulate environmental conditions by precisely controlling temperature and humidity levels for testing products, materials, or components.
2. Do you offer different types of temperature and humidity test chambers?
Yes, we do! Labotronics offers a wide range of temperature and humidity test chambers, including benchtop models, floor-standing units, and walk-in chambers to meet various environmental testing requirements.
3. How do I choose the right chamber for my application?
It depends on the size of your test sample, the required temperature/humidity range, and your test standards. Our team can help you select the right model based on your specific testing needs and industry requirements.
4. Are your chambers suitable for long-duration tests?
Yes. Our chambers are designed for continuous operation and can run long test cycles ranging from a few hours to several days or weeks, without interruption.
Still have questions?
If you cannot find answer to your question in our FAQ, you can always
contact us. We will answer shortly!
