Vertical Autoclave LB-25VCA

Name: Vertical Autoclave LB-25VCA
Brand: Labotronics
SKU: LB-25VCA
Rating: 4.7 (547 reviews)

Vertical Autoclave LB-25VCA has a 50 L SUS 316 stainless steel chamber with 0 to 134 °C temperature range for efficient sterilization. It can withstand a maximum working pressure of 0.23 MPa, ensuring safe operation under high-pressure conditions. It features computer-controlled sterilization cycles for precise and efficient operation. Our vertical autoclave is equipped with an LCD touch control panel for easy and intuitive operation.

$ 8312.5

Download Catalog

Specifications

Capacity	50 L
Temperature Range	0 to 134 °C
Maximum Working Temperature	134 °C
Temperature Uniformity	≤ ± 1 °C
Working Pressure	0.22 MPa
Maximum Working Pressure	0.23 MPa
Timer Range	0 to 99 min / 0 to 99 hr 59 min
Power Consumption	3 kW
Power Supply	AC 220 V; 50 Hz
Interior Dimension	Φ 340 × 550 mm
Exterior Dimension	650 × 410 × 1140 mm
Packaging Dimension	730 × 500 × 1290 mm
Net Weight	83 kg
Gross Weight	102 kg

Features

Quick-opening handwheel
Safety interlock
Built-in exhaust cooling
Water cut-off protection
Auto buzzer stop
Double-layer mesh basket
Steam exhaust filter
Optional drying system

Applications

Vertical Autoclave LB-25VCA is used for sterilizing instruments, dressings, liquids, culture media, and laboratory waste. It is suitable for hospitals, research institutes, disease control centers, and P2 biological laboratories.

1. What is the primary purpose of a Labotronics vertical autoclave?

Labotronics vertical autoclave is designed for high-efficiency steam sterilization, ensuring complete decontamination of laboratory and clinical instruments, media, and materials.

2. How does microcomputer control technology benefit Labotronics vertical autoclaves?

Labotronics vertical autoclaves use advanced microcomputer control to automate all sterilization phases, providing consistent performance with minimal operator intervention.

3. What makes the touchscreen interface on Labotronics vertical autoclaves useful?

Labotronics vertical autoclaves feature a user-friendly touchscreen interface that allows easy monitoring of temperature, pressure, and cycle progress for precise operation.

4. Do Labotronics vertical autoclaves ensure safety during operation?

Yes. Labotronics vertical autoclaves are equipped with multiple safety features including overpressure protection and automatic steam exhaust, ensuring safe use for operators.

5. How do Labotronics vertical autoclaves maintain temperature accuracy?

Labotronics vertical autoclaves provide uniform temperature distribution with precision controls, guaranteeing consistent sterilization performance across all loads.
