Horizontal Laminar Flow Cabinet LB-10LFH

Horizontal Laminar Flow Cabinet LB-10LFH offers ISO Class 5 cleanliness with precise vertical airflow speed of 0.3 to 0.6 m/s. It is equipped with HEPA filters, ensuring reliable sterile conditions. The double-sided glass window allows enhanced visibility and natural lighting. Our cabinet features a push-button LCD control panel for simple operation and continuous airflow monitoring.

$ 4812.5

Download Catalog

Specifications

Cleanliness ISO Class 5
Airflow Direction Vertical
Average Airflow Speed 0.3 to 0.6 m/s
Operators Double people /Single side
HEPA Filter 1 × 452 × 485 × 30 mm ; 2 × 610 × 610 × 50 mm
Sterilization Mode UV sterilization
Colony Count ≤ 0.5 cfu/ Dish 0.5h
Luminance ≥ 300 lx
Lighting Lamp 8 W × 1
UV Lamp 8 W × 2
Noise Level ≤ 67dB
Display Push-button LCD Panel
Maximum Power 180 W
Power Supply 230 V ± 10 %, 50 to 60 Hz
Internal Dimension (W × D × H) 1360 × 690 × 520 mm
External Dimension (W × D × H) 1500 × 725 × 1625 mm
Packaging Dimension 1600 × 825 × 1780 mm
Net Weight 158 kg
Gross Weight 190 kg

Features

  • Adjustable airflow speed

  • UV sterilization lamp

  • Interlock function

  • Corrosion-resistant surface

  • Spare socket design

  • Universal casters with brakes

Applications

Horizontal Laminar Flow Cabinet LB-10LFH used for tissue culture, media preparation, sterile filling, and inspection processes. It is ideal for the sterilization process in pharmaceutical, biotechnology, and diagnostic laboratories.

Horizontal Laminar Flow Cabinet LB-10LFH
Horizontal Laminar Flow Cabinet LB-10LFH

Get Quote

Frequently asked questions For Horizontal Laminar Flow Cabinet

1. What types of work can I perform inside the LB-10LFH Horizontal Laminar Flow Cabinet?

It’s ideal for non-hazardous applications requiring a sterile workspace, such as microbiology, plant tissue culture, electronics assembly, pharmaceutical preparation, and quality control testing.

2. How does the LB-10LFH maintain a contamination-free work area?

It uses a high-efficiency HEPA filter to remove 99.99% of airborne particles down to 0.3 microns, while a continuous horizontal airflow sweeps particles away from the work surface.

3. How do I know if the airflow is working correctly?

The LB-10LFH features an airflow velocity display and visual indicators that alert users to any drop in airflow, ensuring consistent performance.

4. How does the LB-10LFH ensure operator comfort and efficiency?

The LB-10LFH has a wide viewing window, a low-noise motor, and bright LED lighting that ensures a comfortable workspace for extended periods.

5. What is a Horizontal Laminar Flow Cabinet?

Labotronics Horizontal Laminar Flow Cabinet is a workstation that provides a sterile environment by passing air through a HEPA filter and directing it horizontally across the work surface to protect sensitive materials from airborne contaminants.

6. Which industries can benefit from the Horizontal Laminar Flow Cabinet?

Industries such as pharmaceuticals, biotechnology, electronics, food processing, and research laboratories benefit from this cabinet, as it provides a sterile, particle-free workspace for sensitive operations.

7. Is the Horizontal Laminar Flow Cabinet safe for operators and samples?

Yes, it is designed to protect samples from contamination using HEPA-filtered unidirectional airflow. The smooth airflow prevents particles from entering the work area while maintaining operator comfort.

8. What benefits does a horizontal laminar flow cabinet offer over a traditional workbench?

Our Horizontal Laminar Flow Cabinet offers contamination-free conditions, uniform airflow distribution, reduced turbulence, and better sample protection, making it ideal for sterile applications like microbiology, tissue culture, and electronics assembly.
