Labotronics Muffle Furnace LB-31MFF features a 27 L capacity, 1600°C continuous working temperature, MoSi₂ heating element, B-type thermocouple, and 50-segment programmable PID auto control. 400 V single-phase operation and ±1°C temperature accuracy. This high-temperature muffle furnace supports controlled heating and thermal processing.
$ 7018.75
Download CatalogSpecifications
| Capacity | 27 L |
| Chamber Size | 20 L |
| Continuous Working Temperature | 1600°C |
| Maximum Power | 10 kW |
| Voltage | 400 V, 50 Hz, Single Phase |
| Heating Element | MoSi₂ |
| Thermocouple | B Type, Pt-Rh to Pt-Rh |
| Temperature Control | 50-Segment Programmable, PID Auto Control |
| Suggested Heating Rate | ≤10°C/min |
| Temperature Accuracy | ±1°C |
| Heat Capacity Inside Chamber | ≤80 kWh |
| Temperature Controller | Yudian 708 |
| Controller Measuring Accuracy | 0.2% of Full Scale |
| Programmable Segments | Up to 50 Segments |
| Controller Power Consumption | ≤5 W |
| Controller Power Input | 85–264 V AC, 50–60 Hz |
| Chamber Size (W × H × D) | 300 × 300 × 300 mm |
| Weight | 337 kg |
Features
Applications
Muffle Furnace LB-31MFF is suitable for material research and ceramic research laboratories, supporting research work that involves controlled heating and thermal processing of materials.
Frequently asked questions For Muffle Furnace
1. What are muffle furnaces used for?
Our muffle furnaces are used for high-temperature heating in laboratories and industrial settings. It’s ideal for applications such as ashing, heat treatment, material testing, and ceramics processing.
2. Does Labotronics offer different models of muffle furnaces?
Yes, Labotronics offers a wide range of muffle furnace models with different chamber sizes, temperature capacities, and control options to accommodate various laboratory and industrial requirements.
3. Are your muffle furnaces easy to operate?
Absolutely. Labotronics furnaces are designed with user-friendly digital controllers for precise temperature control and simple operation.
4. What safety features are included in your muffle furnaces?
Labotronics furnaces typically include features such as over-temperature protection, ceramic insulation, and door safety switches.
Still have questions?
If you cannot find answer to your question in our FAQ, you can always
contact us. We will answer shortly!
| Capacity | 1 L |
| Working Temperature Range | 0 to 1600℃ |
| Maximum Temperature | 1700℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 10℃/min (Adjustable) |
| Capacity | 1 L |
| Working Temperature Range | 0 to 1100℃ |
| Maximum Temperature | 1200℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 30℃/min (Adjustable) |
| Capacity | 4.5 L |
| Working Temperature Range | 0 to 1600℃ |
| Maximum Temperature | 1700℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 10℃/min (Adjustable) |
| Capacity | 1L |
| Working Temperature Range | 0 to 1300℃ |
| Maximum Temperature | 1400℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 20℃/min |
| Capacity | 12 L |
| Working Temperature Range | 0 to 1300℃ |
| Maximum Temperature | 1400℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 20℃/min |
| Capacity | 4.5L |
| Working Temperature Range | 0 to 1300℃ |
| Maximum Temperature | 1400℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 20℃/min |
| Capacity | 27 L |
| Working Temperature | 1100 ℃ |
| Maximum Temperature | 1200 ℃ |
| Temperature Control Accuracy | ± 1 ℃ |
| Heating Rate | 0 to 20 ℃/min |
| Capacity | 12 L |
| Working Temperature Range | 0 to 1100℃ |
| Maximum Temperature | 1200℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 30℃/min (Adjustable) |
| Capacity | 36 L |
| Working Temperature Range | 0 to 1100℃ |
| Maximum Temperature | 1200℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 30℃/min (Adjustable) |
| Maximum Temperature | 1100℃ |
| Temperature Accuracy | ±2℃ |
| Heating Rate | ≤ 30℃/min |
| Heating Element | Dental silicon carbide rods |
| Program Stage | 50 stages |
| Capacity | 4.5 L |
| Working Temperature Range | 0 to 1100℃ |
| Maximum Temperature | 1200℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 30℃/min (Adjustable) |
| Maximum temperature | 1200 ℃ |
| Working temperature | 1100 ℃ |
| Temperature controller | Digital PID controller (Program: 30 segment) |
| Temperature control accuracy | ± 1℃ |
| Heating | Resistance wire |
| Capacity | 36 L |
| Working Temperature Range | 0 to 1600℃ |
| Maximum Temperature | 1700℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 10℃/min (Adjustable) |
| Capacity | 36 L |
| Working Temperature Range | 0 to 1300℃ |
| Maximum Temperature | 1400℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 20℃/min |
| Capacity | 12 L |
| Working Temperature Range | 0 to 1600℃ |
| Maximum Temperature | 1700℃ |
| Temperature Precision | ±1℃ |
| Heating Rate | 0 to 10℃/min (Adjustable) |
